Chauvin Arnoux, France

Single / Three Phase Power Quality Analyzer

These are category III (IEC 1010) 600V single/Three-phase AC+DC power quality analyser with graphic display. It measures the RMS values, powers, and disturbances of electricity distribution networks and can be used for a snapshot of the main characteristics of a network and to track variations of the different parameters over time.
It is compact and impact-resistant, and its ergonomy and simple interface make using it pleasant and intuitive.
The C.A 8230 can be used not only for a snapshot of the main characteristics of a network, but also to track their variations over time. The multitasking measurement system simultaneously performs all functions required for the measurement of the various quantities, detection, continuous recording, and display without constraint.

2/4 Channel Portable 40/100 Mhz DSO / Analyser

  • • Five complementary tools in one: OSCILLOSCOPE; MULTIMETER; FFT ANALYZER; HARMONIC ANALYZER; and RECORDER
  • • Sampling rate 1 GS/s in one-shot and 50 GS/s in ETS - memory depth of 2.5 k per channel in "Oscilloscope" mode
  • • 2 or 4 isolated measurement channels, 600 V, Cat III, and up to 8 curves on screen
  • • "Real time" FFT analysis standard and calculation functions on the channels
  • • 2 or 4 digital multimeters, TRMS, 8,000 points, 50 kHz, independent
  • • Colour LCD touch screen
  • • 33 direct command keys and "Windows-like" menus on screen
  • • Input terminals (plug and play) and associated smart sensors
  • • Multi-interface communication connector: RS232, Centronics, and Ethernet with WEB server

For more information.visit:-

www.chauvin-arnoux.com
